MPU-6050
零件编号：
MPU-6050
产品分类：
刀具、剪刀、切削工具
制造商：
AiStorm
描述：
Accelerometer, Gyroscope, 6 Axis Sensor I2C Output
包装：
-
ROHS状态：
No
货币：
USD
PDF：
资料
Digital-output X-, Y-, and Z-Axis angular rate sensors (gyroscopes) with a user-programmable fullscale range of ±250, ±500, ±1000, and ±2000°/sec
External sync signal connected to the FSYNC pin supports image, video and GPS synchronization
Integrated 16-bit ADCs enable simultaneous sampling of gyros
Enhanced bias and sensitivity temperature stability reduces the need for user calibration
Improved low-frequency noise performance
Digitally-programmable low-pass filter
Gyroscope operating current: 3.6mA
Standby current: 5µA
Factory calibrated sensitivity scale factor
User self-test
