Manufacturer |
Littelfuse Inc.
|
|
|
Series |
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Polymeric
|
|
|
Voltage - Max |
60V
|
|
|
Current - Hold (Ih) (Max) |
140 mA
|
|
|
Current - Trip (It) |
280 mA
|
|
|
Current - Max |
10 A
|
|
|
Time to Trip |
8 ms
|
|
|
Resistance - Initial (Ri) (Min) |
1.5 Ohms
|
|
|
Resistance - Post Trip (R1) (Max) |
6 Ohms
|
|
|
Operating Temperature |
-40°C ~ 85°C
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
1812 (4532 Metric), Concave
|
|
|
Size / Dimension |
0.179" L x 0.128" W (4.55mm x 3.24mm)
|
|
|
Height - Seated (Max) |
-
|
|
|
Thickness (Max) |
0.035" (0.89mm)
|
|
|
Lead Spacing |
-
|
|
|
Approval Agency |
CSA, TUV, UL
|
