Category |
Discrete Semiconductor Products
Diodes
Rectifiers
Single Diodes
|
|
|
Mfr |
Vishay General Semiconductor - Diodes Division |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Technology |
Standard |
|
|
Voltage - DC Reverse (Vr) (Max) |
200 V
|
|
|
Current - Average Rectified (Io) |
1A
|
|
|
Voltage - Forward (Vf) (Max) @ If |
920 mV @ 1 A
|
|
|
Speed |
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Reverse Recovery Time (trr) |
25 ns
|
|
|
Current - Reverse Leakage @ Vr |
5 µA @ 200 V
|
|
|
Capacitance @ Vr, F |
10pF @ 4V, 1MHz
|
|
|
Mounting Type |
Surface Mount |
|
|
Package / Case |
DO-214AC, SMA |
|
|
Supplier Device Package |
DO-214AC (SMA)
|
|
|
Operating Temperature - Junction |
-55°C ~ 150°C
|
|
|
Base Product Number |
ES1 |
