TPS72301DBVR

The TPS723 low-dropout (LDO) negative voltage
regulator offers an ideal combination of features to
support low noise applications. This device is capable
of operating with input voltages from –10 V to –2.7 V,
and support outputs from –10 V to –1.2 V. This
regulator is stable with small, low-cost ceramic
capacitors, and include enable (EN) and noise
reduction (NR) functions. Thermal short-circuit and
over-current protections are provided by internal
detection and shutdown logic. High PSRR (65 dB at
1 kHz) and low noise (60 μVRMS) make the TPS723
ideal for low-noise applications.
The TPS723 uses a precision voltage reference to
achieve 2% overall accuracy over load, line, and
temperature variations. Available in a small SOT23-5
package, the TPS723 is fully specified over a
temperature range of –40°C to 125°C.


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • Ultralow noise: 60 μVRMS typical
    • High PSRR: 65 dB typical at 1 kHz
    • Low dropout voltage: 280 mV typical at 200 mA,
    2.5 V
    • Available in –2.5-V and adjustable (–1.2 V to
    –10 V) versions
    • Stable with a 2.2-μF ceramic output capacitor
    • Less than 2-μA typical quiescent current in
    shutdown mode
    • 2% overall accuracy
    (line, load, temperature)
    • Thermal and over-current protection
    • Packages:
    – SOT23-5 (DBV)
    – SOT23-5 (DDC)
    – WSON-6 (DRV)
    • Operating junction temperature range: –40°C to
    125°C
