TPS55340RTER
INQUIRY ONLINE
|
Category
|
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators – DC DC Switching Regulators
|
|
|
Mfr
|
Texas Instruments
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Function
|
Step-Up
|
|
|
Output Configuration
|
Positive, Isolation Capable
|
|
|
Topology
|
Boost
|
|
|
Output Type
|
Adjustable
|
|
|
Number of Outputs
|
1
|
|
|
Voltage – Input (Min)
|
2.9V
|
|
|
Voltage – Input (Max)
|
32V
|
|
|
Voltage – Output (Min/Fixed)
|
2.9V
|
|
|
Voltage – Output (Max)
|
38V
|
|
|
Current – Output
|
5.25A (Switch)
|
|
|
Frequency – Switching
|
94kHz ~ 1.14MHz
|
|
|
Synchronous Rectifier
|
No
|
|
|
Operating Temperature
|
-40°C ~ 125°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
16-WFQFN Exposed Pad
|
|
|
Supplier Device Package
|
16-WQFN (3×3)
|
|
|
Base Product Number
|
TPS55340
|
