TPD1E0B04DPYR
INQUIRY ONLINE
|
Category
|
Circuit Protection
TVS
Diodes
|
|
|
Mfr
|
Texas Instruments
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Type
|
Zener
|
|
|
Bidirectional Channels
|
1
|
|
|
Voltage – Reverse Standoff (Typ)
|
3.6V
|
|
|
Voltage – Breakdown (Min)
|
6.7V (Typ)
|
|
|
Voltage – Clamping (Max) @ Ipp
|
19V
|
|
|
Current – Peak Pulse (10/1000µs)
|
1.7A (8/20µs)
|
|
|
Power – Peak Pulse
|
15W
|
|
|
Power Line Protection
|
No
|
|
|
Applications
|
General Purpose
|
|
|
Capacitance @ Frequency
|
0.15pF @ 1MHz
|
|
|
Operating Temperature
|
-40°C ~ 125°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
0402 (1006 Metric)
|
|
|
Supplier Device Package
|
2-X1SON (1x.60)
|
|
|
Base Product Number
|
TPD1E0B04
|
