TMS320F28069PZT

• High-efficiency 32-bit CPU (TMS320C28x)
– 90 MHz (11.11-ns cycle time)
– 16 × 16 and 32 × 32 Multiply and Accumulate
(MAC) operations
– 16 × 16 dual MAC
– Harvard bus architecture
– Atomic operations
– Fast interrupt response and processing
– Unified memory programming model
– Code-efficient (in C/C++ and Assembly)
• Floating-Point Unit (FPU)
– Native single-precision floating-point operations
• Programmable Control Law Accelerator (CLA)
– 32-bit floating-point math accelerator
– Executes code independently of the main CPU
• Viterbi, Complex Math, CRC Unit (VCU)
– Extends C28x instruction set to support
complex multiply, Viterbi operations, and Cyclic
Redundency Check (CRC)
• Embedded memory
– Up to 256KB of flash
– Up to 100KB of RAM
– 2KB of One-Time Programmable (OTP) ROM
• 6-channel Direct Memory Access (DMA)
• Low device and system cost
– Single 3.3-V supply
– No power sequencing requirement
– Integrated power-on reset and brownout reset
– Low-power operating modes
– No analog support pin
• Endianness: Little endian
• JTAG boundary scan support
– IEEE Standard 1149.1-1990 Standard Test
Access Port and Boundary Scan Architecture
• Clocking
– Two internal zero-pin oscillators
– On-chip crystal oscillator/external clock input
– Watchdog timer module
– Missing clock detection circuitry
• Peripheral Interrupt Expansion (PIE) block that
supports all peripheral interrupts
• Three 32-bit CPU timers
• Advanced control peripherals
• Up to 8 Enhanced Pulse-Width Modulator (ePWM)
modules
– 16 PWM channels total (8 HRPWM-capable)
– Independent 16-bit timer in each module
• Three input Enhanced Capture (eCAP) modules
• Up to 4 High-Resolution Capture (HRCAP)
modules
• Up to 2 Enhanced Quadrature Encoder Pulse
(eQEP) modules
• 12-bit Analog-to-Digital Converter (ADC), dual
Sample-and-Hold (S/H)
– Up to 3.46 MSPS
– Up to 16 channels
• On-chip temperature sensor
• 128-bit security key and lock
– Protects secure memory blocks
– Prevents reverse-engineering of firmware
• Serial port peripherals
– Two Serial Communications Interface (SCI)
[UART] modules
– Two Serial Peripheral Interface (SPI) modules
– One Inter-Integrated-Circuit (I2C) bus
– One Multichannel Buffered Serial Port (McBSP)
bus
– One Enhanced Controller Area Network
(eCAN)
– Universal Serial Bus (USB) 2.0
(see Device Comparison for availability)
• Full-speed device mode
• Full-speed or low-speed host mode
• Up to 54 individually programmable, multiplexed
General-Purpose Input/Output (GPIO) pins with
input filtering
• Advanced debug features
– Analysis and breakpoint functions
– Real-time debug through hardware
• Package options
– 80-pin PFP and 100-pin PZP PowerPAD™
Thermally Enhanced Thin Quad Flatpacks
(HTQFPs)
– 80-pin PN and 100-pin PZ Low-Profile Quad
Flatpacks (LQFPs)
• Temperature options
– T: –40°C to 105°C
– S: –40°C to 125°C
– Q: –40°C to 125°C (AEC Q100 qualification for
automotive applications)
