TLV70433DBVR

The TLV704 low-dropout (LDO) linear voltage
regulator is a low quiescent current device that
offers the benefits of a wide input voltage range
and low-power operation in miniaturized packaging.
Thus, the TLV704 is designed for battery-powered
applications and as a power-management attachment
to low-power microcontrollers.
The TLV704 LDO supports a low dropout of typically
850 mV at 100 mA of load current. The low quiescent
current (3.4 μA typically) is stable over the entire
range of output load current (0 mA to 150 mA). The
TLV704 also features an internal soft-start to lower the
inrush current. The built-in overcurrent limit protection
helps protect the regulator in the event of a load short
or fault.
The TLV704 is available in a 2.90-mm × 1.60-mm
SOT23-5 package, which is useful for cost-effective
board manufacturing.


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • Input voltage range:
    – 2.5 V to 24 V (30 V max for new chip only)
    • Available output voltage options:
    – Fixed: 1.8 V to 5 V
    • Output current: Up to 150 mA
    • Very low IQ: 3.4 μA at 100-mA load current
    • Stable with output capacitor ≥ 0.47 μF
    • Overcurrent protection
    • Package: 5-pin SOT-23 (DBV)
    • Operating junction temperature: –40°C to +125°C
