TL074CN

The TL07xH (TL071H, TL072H, and TL074H) family
of devices are the next-generation versions of the
industry-standard TL07x (TL071, TL072, and TL074)
devices. These devices provide outstanding value for
cost-sensitive applications, with features including low
offset (1 mV, typical), high slew rate (20 V/μs), and
common-mode input to the positive supply. High ESD
(1.5 kV, HBM), integrated EMI and RF filters, and
operation across the full –40°C to 125°C enable the
TL07xH devices to be used in the most rugged and
demanding applications.

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • High slew rate: 20 V/μs (TL07xH, typ)
    • Low offset voltage: 1 mV (TL07xH, typ)
    • Low offset voltage drift: 2 μV/°C
    • Low power consumption: 940 μA/ch (TL07xH, typ)
    • Wide common-mode and differential
    voltage ranges
    – Common-mode input voltage range
    includes VCC+
    • Low input bias and offset currents
    • Low noise:
    Vn = 18 nV/√Hz (typ) at f = 1 kHz
    • Output short-circuit protection
    • Low total harmonic distortion: 0.003% (typ)
    • Wide supply voltage:
    ±2.25 V to ±20 V, 4.5 V to 40 V
