    STM32F030C8T6

    The STM32F030x4/x6/x8/xC microcontrollers incorporate the high-performance Arm®
    Cortex®-M0 32-bit RISC core operating at a 48 MHz frequency, high-speed embedded
    memories (up to 256 Kbytes of Flash memory and up to 32 Kbytes of SRAM), and an
    extensive range of enhanced peripherals and I/Os. All devices offer standard
    communication interfaces (up to two I2Cs, up to two SPIs and up to six USARTs), one 12-bit
    ADC, seven general-purpose 16-bit timers and an advanced-control PWM timer.
    The STM32F030x4/x6/x8/xC microcontrollers operate in the -40 to +85 °C temperature
    range from a 2.4 to 3.6V power supply. A comprehensive set of power-saving modes allows
    the design of low-power applications.
    The STM32F030x4/x6/x8/xC microcontrollers include devices in four different packages
    ranging from 20 pins to 64 pins. Depending on the device chosen, different sets of
    peripherals are included. The description below provides an overview of the complete range
    of STM32F030x4/x6/x8/xC peripherals proposed.
    These features make the STM32F030x4/x6/x8/xC microcontrollers suitable for a wide range
    of applications such as application control and user interfaces, handheld equipment, A/V
    receivers and digital TV, PC peripherals, gaming and GPS platforms, industrial applications,
    PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVACs.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Core: Arm® 32-bit Cortex®-M0 CPU, frequency
      up to 48 MHz
      • Memories
      – 16 to 256 Kbytes of Flash memory
      – 4 to 32 Kbytes of SRAM with HW parity
      • CRC calculation unit
      • Reset and power management
      – Digital & I/Os supply: VDD = 2.4 V to 3.6 V
      – Analog supply: VDDA = VDD to 3.6 V
      – Power-on/Power down reset (POR/PDR)
      – Low power modes: Sleep, Stop, Standby
      • Clock management
      – 4 to 32 MHz crystal oscillator
      – 32 kHz oscillator for RTC with calibration
      – Internal 8 MHz RC with x6 PLL option
      – Internal 40 kHz RC oscillator
      • Up to 55 fast I/Os
      – All mappable on external interrupt vectors
      – Up to 55 I/Os with 5V tolerant capability
      • 5-channel DMA controller
      • One 12-bit, 1.0 µs ADC (up to 16 channels)
      – Conversion range: 0 to 3.6 V
      – Separate analog supply: 2.4 V to 3.6 V
      • Calendar RTC with alarm and periodic wakeup
      from Stop/Standby
      • 11 timers
      – One 16-bit advanced-control timer for
      six-channel PWM output
      – Up to seven 16-bit timers, with up to four
      IC/OC, OCN, usable for IR control
      decoding
      – Independent and system watchdog timers
      – SysTick timer

      • Communication interfaces
      – Up to two I2C interfaces
      – Fast Mode Plus (1 Mbit/s) support on
      one or two I/Fs, with 20 mA current sink
      – SMBus/PMBus support (on single I/F)
      – Up to six USARTs supporting master
      synchronous SPI and modem control; one
      with auto baud rate detection
      – Up to two SPIs (18 Mbit/s) with 4 to 16
      programmable bit frames
      • Serial wire debug (SWD)
      • All packages ECOPACK®2
