SPBT2632C2A.AT2

The SPBT2632C2A.AT2 is an easy to use Bluetooth module, compliant with Bluetooth v3.0.
The module is the smallest form factor available which provides a complete RF platform.
The SPBT2632C2A.AT2 enables electronic devices with wireless connectivity, not requiring
any RF experience or expertise for integration into the final product. The
SPBT2632C2A.AT2 module, being a certified solution, optimizes the time to market of the
final applications.
The module is designed for maximum performance in a minimal space including fast speed
UART and 7 general purpose I/O lines, several serial interface options, and up to 560 kbps
transmission speed with SPP service active, 250 kbps with iAP1 service active.
Optimized design allows the integration of a complete working Bluetooth modem, including
antenna, in the minimum possible size; only an additional external LPO (low power
oscillator) is required to enable low power mode capability.
The SPBT2632C2A.AT2 is a surface mount PCB module that provides fully embedded,
ready to use Bluetooth wireless technology. The reprogrammable Flash memory contains
embedded firmware for serial cable replacement using the Bluetooth SPP profile.
Embedded Bluetooth AT2 command firmware is a friendly interface, which realizes a simple
control for cable replacement, enabling communication with most Bluetooth enabled
devices, provided that the devices support the SPP profile. The SPBT2632C2A.AT2,
supporting iAP1 profile, provides communication with Android, smartphone, and Apple® iOS
Bluetooth enabled devices.
An Apple authentication IC is required to exchange data with an Apple device or access an
Apple device application. The AT2 FW includes the Bluetooth SPP profile capable of
recognizing the Apple authentication chip.

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

     Bluetooth® radio
    – Fully embedded Bluetooth v3.0 with
    profiles
    – Class 2 module
    – Complete RF ready module
    – 128-bit encryption security
    – Integrated antenna
    – Multipoint capability
     ST micro Cortex-M3 microprocessor up to
    72 MHz (256 kb Flash, 48 kb RAM)
     Modem transmitter speed
    – Supported transmission speed with SPP
    service active: 560 kbps
     General I/O
    – 7 general purpose I/Os
    – 1 LPO input
     User interface
    – AT2 command set (abSerial)
    – Firmware upgrade over UART
     EU, FCC, IC and Bluetooth qualified
     Single voltage supply: 2.5 V typical
     Micro-sized form factor: 11.6 x 13.5 x 2.9 mm
     Operating temperature range: -40 °C to 85 °C.
