    SN74LVC1G175DBVR

    This single D-type flip-flop is designed for 1.65-V to 5.5-V VCC operation.

    The SN74LVC1G175 device has an asynchronous clear (CLR) input. When CLR is high, data from the input pin (D) is transferred to the output pin (Q) on the clock’s (CLK) rising edge. When CLR is low, Q is forced into the low state, regardless of the clock edge or data on D.

    NanoFree™ package technology is a major breakthrough in IC packaging concepts, using the die as the package.

    This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Available in the Texas Instruments
        NanoFree™ Package
      • Supports 5-V VCC Operation
      • Inputs Accept Voltages to 5.5 V
      • Supports Down Translation to VCC
      • Max tpd of 4.3 ns at 3.3 V
      • Low Power Consumption, 10-µA Max ICC
      • ±24-mA Output Drive at 3.3 V
      • Ioff Supports Live Insertion, Partial-Power-Down
        Mode, and Back-Drive Protection
      • Latch-Up Performance Exceeds 100 mA Per
        JESD 78, Class II
      • ESD Protection Exceeds JESD 22
        • 2000-V Human-Body Model (A114-A)
        • 200-V Machine Model (A115-A)
        • 1000-V Charged-Device Model (C101)
