SN74LV125ADR

• 2-V to 5.5-V VCC Operation
• Max tpd of 6 ns at 5 V
• Typical VOLP (Output Ground Bounce)
< 0.8 V at VCC = 3.3 V, TA = 25°C
• Typical VOHV (Output VOH Undershoot)
> 2.3 V at VCC = 3.3 V, TA = 25°C
• Support Mixed-Mode Voltage Operation on
All Ports
• Ioff Supports Partial-Power-Down Mode Operation
• Latch-Up Performance Exceeds 250 mA Per
JESD 17
• ESD Protection Exceeds JESD 22
– 4000-V Human-Body Model
– 200-V Machine Model
– 2000-V Charged-Device Model
