SN74HC245DBR

These octal bus transceivers are designed for asynchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements.

The devices allow data transmission from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable ( OE) input can be used to disable the device so that the buses are effectively isolated.

Category: Transceivers

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

Wide Operating Voltage Range of 2 V to 6 V
High-Current 3-State Outputs Drive Bus Lines Directly or Up to 15 LSTTL Loads
Low Power Consumption, 80-µA Max I_CC
Typical t_pd = 12 ns
±6-mA Output Drive at 5 V
Low Input Current of 1 µA Max
On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
