SN6501DBVR

The SN6501 is a monolithic oscillator/power-driver,
specifically designed for small form factor, isolated
power supplies in isolated interface applications. The
device drives a low-profile, center-tapped transformer
primary from a 3.3-V or 5-V DC power supply. The
secondary can be wound to provide any isolated
voltage based on transformer turns ratio.
The SN6501 consists of an oscillator followed by a
gate drive circuit that provides the complementary
output signals to drive the ground referenced Nchannel power switches. The internal logic ensures
break-before-make action between the two switches.
The SN6501 is available in a small SOT-23 (5)
package, and is specified for operation at
temperatures from –40°C to 125°C.


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • Push-pull driver for small transformers
    • Single 3.3-V or 5-V supply
    • High primary-side current drive:
    – 5-V Supply: 350 mA (Max)
    – 3.3-V Supply: 150 mA (Max)
    • Low ripple on rectified output permits small output
    capacitors
    • Small 5-Pin SOT-23 Package
