SG3525AP013TR
INQUIRY ONLINE
|
Category
|
Integrated Circuits (ICs)
Power Management (PMIC)
DC DC Switching Controllers
|
|
|
Manufacturer
|
STMicroelectronics
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Output Type
|
Transistor Driver
|
|
|
Function
|
Step-Down, Step-Up/Step-Down
|
|
|
Output Configuration
|
Positive
|
|
|
Topology
|
Buck, Push-Pull
|
|
|
Number of Outputs
|
2
|
|
|
Output Phases
|
1
|
|
|
Voltage – Supply (Vcc/Vdd)
|
8V ~ 35V
|
|
|
Frequency – Switching
|
100Hz ~ 400kHz
|
|
|
Duty Cycle (Max)
|
49%
|
|
|
Synchronous Rectifier
|
Yes
|
|
|
Clock Sync
|
Yes
|
|
|
Serial Interfaces
|
–
|
|
|
Control Features
|
Enable, Soft Start
|
|
|
Operating Temperature
|
0°C ~ 70°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
16-SOIC (0.154″, 3.90mm Width)
|
|
|
Supplier Device Package
|
16-SO
|
|
|
Base Product Number
|
SG3525
|
