SBR3U40P1-7

 Case: POWERDI123
 Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
 Moisture Sensitivity: Level 1 per J-STD-020
 Polarity Indicator: Cathode Band
 Terminals: Finish – Matte Tin Annealed over Copper
Leadframe; Solderable per MIL-STD-202, Method 208
 Weight: 0.018 grams (Approximate)

Categories: Diodes, Transistors and Thyristors, Rectifiers

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

 Ultra Low Forward Voltage Drop
 Superior Reverse Avalanche Capability
 Patented Interlocking Clip Design for High Surge Current
Capacity
 Patented Super Barrier Rectifier Technology
 Soft, Fast Switching Capability
 +150°C Operating Junction Temperature
 Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
 Halogen and Antimony Free. “Green” Device (Note 3)
 Qualified to AEC-Q101 Standards for High Reliability
