RT9611AGQW

IC GATE DRVR HI/LOW SIDE 8WDFN


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    Category
    Integrated Circuits (ICs)
    Power Management (PMIC)
    Gate Drivers
    Manufacturer
    Richtek USA Inc.
    Series
    Packaging
    Tape & Reel (TR)
    Cut Tape (CT)
    Digi-Reel®
    Part Status
    Active
    DigiKey Programmable
    Not Verified
    Driven Configuration
    High-Side or Low-Side
    Channel Type
    Synchronous
    Number of Drivers
    2
    Gate Type
    N-Channel MOSFET
    Voltage – Supply
    4.5V ~ 13.5V
    Logic Voltage – VIL, VIH
    Current – Peak Output (Source, Sink)
    Input Type
    Non-Inverting
    High Side Voltage – Max (Bootstrap)
    15 V
    Rise / Fall Time (Typ)
    12ns, 12ns
    Operating Temperature
    -40°C ~ 85°C (TA)
    Mounting Type
    Surface Mount
    Package / Case
    8-WFDFN Exposed Pad
    Supplier Device Package
    8-WDFN-EL (3×3)
    Base Product Number
    RT9611
