RC0402FR-071K65L

The resistor is constructed on top of a high-grade
ceramic body. Internal metal electrodes are added
on each end to make the contacts to the thick
film resistive element. The composition of the
resistive element is a noble metal imbedded into a
glass and covered by a second glass to prevent
environmental influences. The resistor is laser
trimmed to the rated resistance value. The
resistor is covered with a protective epoxy
coat, finally the two external terminations (matte
tin on Ni-barrier) are added, as shown in Fig.9.

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

     Halogen Free Epoxy
     RoHS compliant
     Products with lead free
    terminations meet RoHS
    requirements
     Pb-glass contained in
    electrodes, resistors element
    and glass are exempted by
    RoHS
     Reducing environmentally
    hazardous wastes
     High component and equipment
    reliability
     Saving of PCB space
     None forbidden-materials used in
    products/production
     MSL class: MSL 1
