PCA9685BS,118
INQUIRY ONLINE
|
Category
|
Integrated Circuits (ICs)
Power Management (PMIC)
LED Drivers
|
|
|
Manufacturer
|
NXP USA Inc.
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Type
|
Linear
|
|
|
Topology
|
–
|
|
|
Internal Switch(s)
|
Yes
|
|
|
Number of Outputs
|
16
|
|
|
Voltage – Supply (Min)
|
2.3V
|
|
|
Voltage – Supply (Max)
|
5.5V
|
|
|
Voltage – Output
|
5.5V
|
|
|
Current – Output / Channel
|
25mA
|
|
|
Frequency
|
–
|
|
|
Dimming
|
PWM
|
|
|
Applications
|
Backlight
|
|
|
Operating Temperature
|
-40°C ~ 85°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
28-VQFN Exposed Pad
|
|
|
Supplier Device Package
|
28-HVQFN (6×6)
|
|
|
Base Product Number
|
PCA9685
|
