PA5002.561NLT

1. Actual temperature of the component during system operation (ambient plus
temperature rise) must be within the standard operating range.
2. The saturation current is the current at which the initial inductance is guaranteed
to drop by no more than 40%. The typical inductance at a specified current can be
found on the typical performance curves.
3. The rated current is the DC current required to raise the component temperature by
approximately 40�C. Take note that the components’ performanc varies depending
on the system condition. It is suggested that the component be tested at the system
level, to verify the temperature rise of the component during system operation.
4. The part temperature (ambient+temp rise) should not exceed 155�C under worst
case operating conditions. Circuit design, PCB trace size and thickness, airflow and
other cooling provisions all affect the part temperature. Part temperature should be
verified in the end application.
5. The PM2202.XXXNLT part numbers are AEC-Q200 and IATF16949 certified. The
mechanical dimensions are 100% tested in production but do not necessarily meet a
product capability index (Cpk) >1.33 and therefore may not strictly conform to PPAP.
6. Special Characteristics
