OPA396DCKR

The OPA396 features a combination of high
bandwidth (1 MHz) along with very low quiescent
current (23.5 µA) in a high-precision amplifier. These
features combined with rail-to-rail input and output
make this device an exceptional choice in high-gain,
low-power applications. Ultra-low input bias current of
10 fA, 100 µV of offset (maximum), and 1.2 µV/°C of
drift over temperature help maintain high precision in
ratiometric and amperometric sensor front ends that
have demanding low-power requirements.
The OPA396 uses Texas Instrument’s proprietary
e‑trim™ operational amplifier technology, enabling a
unique combination of ultra-low offset and low input
offset drift without the need for any input switching or
auto-zero techniques. The CMOS-based technology
platform also features a modern, robust output stage
design that is tolerant of high output capacitance,
alleviating stability problems that are common in
typical low-power amplifiers.
