NSI1050-DDBR

The NSi1050 is a isolated CAN transceiver which fully
compatible with the ISO11898-2 standard. The
NSi1050 integrated two channel digital isolators and
a high reliability CAN transceiver. The digital isolator
is silicon oxide isolation based on Novosense
capacity isolation technology. The high integrated
solution can help to simplify system design and
improve reliability. The NSi1050 device is safety
certified by UL1577 support 5kVrms insulation
withstand voltages, while providing high
electromagnetic immunity and low emissions. The
data rate of the NSi1050 is up to 1Mbps. The NSi1050
provides thermal protection and transmit data
dominant time out function.
