NRF5340-QKAA-R
INQUIRY ONLINE
|
Category
|
RF and Wireless
RF Transceiver ICs
|
|
|
Mfr
|
Nordic Semiconductor ASA
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
DigiKey Programmable
|
Not Verified
|
|
|
Type
|
TxRx + MCU
|
|
|
RF Family/Standard
|
802.15.4, Bluetooth
|
|
|
Protocol
|
Bluetooth v5.1, Thread, Zigbee®
|
|
|
Modulation
|
–
|
|
|
Frequency
|
2.4GHz
|
|
|
Data Rate (Max)
|
2Mbps
|
|
|
Power – Output
|
3dBm
|
|
|
Sensitivity
|
-97.5dBm
|
|
|
Memory Size
|
1MB Flash, 256kB RAM
|
|
|
Serial Interfaces
|
ADC, I2S, PWM, SPI, UART, USB
|
|
|
GPIO
|
48
|
|
|
Voltage – Supply
|
1.7V ~ 5.5V
|
|
|
Current – Receiving
|
2.6mA ~ 7mA
|
|
|
Current – Transmitting
|
3.2mA
|
|
|
Operating Temperature
|
-40°C ~ 105°C
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
94-VFQFN Dual Rows, Exposed Pad
|
|
|
Supplier Device Package
|
94-aQFN (7×7)
|
|
|
Base Product Number
|
NRF5340
|
