NFL18SP157X1A3D
INQUIRY ONLINE
| Manufacturer | Murata Electronics |
| Series | EMIFIL®, NFL18 |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Part Status | Obsolete |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Number of Channels | 1 |
| Center / Cutoff Frequency | 150MHz (Cutoff) |
| Attenuation Value | – |
| Resistance – Channel (Ohms) | – |
| Current | 100 mA |
| Values | L = 100nH, C = 34pF |
| ESD Protection | No |
| Operating Temperature | -55°C ~ 125°C |
| Applications | General Purpose |
| Voltage – Rated | 10V |
| Mounting Type | Surface Mount |
| Package / Case | 0603 (1608 Metric), 3 PC Pad |
| Size / Dimension | 0.063″ L x 0.032″ W (1.60mm x 0.80mm) |
| Height | 0.028″ (0.70mm) |
| Base Product Number | NFL18SP |
