    Nexperia USA Inc.

    Common-mode ElectroMagnetic Interference (EMI) filters with integrated ElectroStatic Discharge
    (ESD) protection for one, two and three differential channels. The devices are designed to provide
    low insertion loss for differential high-speed signals on each channel while unwanted commonmode signals are attenuated.
    Each differential channel incorporates two signal lines that are coupled by integrated coils. Diodes
    provide protection to downstream components from ESD voltages up to ±15 kV on each signal line.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • One, two and three differential channels common-mode EMI filters with integrated ESD
      protection
      • ESD protection up to ±15 kV contact discharge according to IEC 61000-4-2
      • Superior common-mode suppression over a wide frequency range
      • Superior RF performance compared to other integrated filters or discrete filters with external
      ESD protection
      • Extremely high symmetry between line pairs
      • Industry-standard Wafer-Level Chip-Scale Packages: WLCSP5, 10 and 15 for smaller footprint
