NCV8177AMX180TCG

The NCV8177 is CMOS LDO regulator featuring 500 mA output
current. The input voltage is as low as 1.6 V and the output voltage can
be set from 0.75 V. It provides very stable and accurate voltage with
low noise and high Power Supply Rejection Ratio (PSRR) suitable for
RF applications. The NCV8177 is suitable for powering RF blocks of
automotive infotainment systems and other power sensitive device.
Due to low power consumption the NCV8177 offers high efficiency
and low thermal dissipation. Small 4−pin XDFN4 1.0 mm x 1.0 mm or
WDFNW8 2 mm x 2 mm packages make the device especially
suitable for space constrained applications.

Category: Power Management (PMIC)

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• Operating Input Voltage Range: 1.6 V to 5.5 V
• Output Voltage Range: 0.7 V to 3.6 V
• Quiescent Current typ. 60 A
• Low Dropout: 200 mV Typ. at 500 mA, VOUT−NOM = 1.8 V
• High Output Voltage Accuracy ±0.8%
• Stable with Small 1 F Ceramic Capacitors
• Over−current Protection
• Thermal Shutdown Protection: 175°C
• With (NCV8177A) and Without (NCV8177B) Output Discharge
Function
• Available in XDFN4 1 mm x 1 mm x 0.4 mm and
WDFNW8 2 mm x 2 mm Packages
• NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
• This is a Pb−Free Device
