NCV8164AMTW180TAG

The NCV8164 is a 300 mA LDO, next generation of high PSRR,
ultra−low noise and low dropout regulators with Power Good open
collector output. Designed to meet the requirements of RF and
sensitive analog circuits, the NCV8164 device provides ultra−low
noise, high PSRR and low quiescent current. The device also offer
excellent load/line transients. The NCV8164 is designed to work with
a 1 F input and a 1 F output ceramic capacitor. It is available in
industry standard TSOP−5, WDFNW6 0.65P, 2 mm x 2 mm and
DFNW8 0.65P, 3 mm x 3 mm.

Category: Power Management (PMIC)

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• Operating Input Voltage Range: 1.6 V to 5.5 V
• Available in Fixed Voltage Option: 1.2 V to 5.0 V
• Adjustable Version Reference Voltage: 1.2 V
• ±2% Accuracy Over Load and Temperature
• Ultra Low Quiescent Current Typ. 30 A
• Standby Current: Typ. 0.1 A
• Very Low Dropout: 110 mV at 300 mA for 3.3 V Variant
• Ultra High PSRR: Typ. 85 dB at 10 mA, f = 1 kHz
• Ultra Low Noise: 9 VRMS (Fixed Version)
• Stable with a 1 F Small Case Size Ceramic Capacitors
• Available in – TSOP−5 3 mm x 1.5 mm x 1 mm CASE 483
♦ WDFNW6 2 mm x 2 mm x 0.75 mm CASE 511DW
♦ DFNW8 3 mm x 3 mm x 0.9 mm CASE 507AD
• NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements
• AEC−Q100 Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
