NCV4276BDTADJRKG
INQUIRY ONLINE
|
Category
|
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators – Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr
|
onsemi
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Not For New Designs
|
|
|
Output Configuration
|
Positive
|
|
|
Output Type
|
Adjustable
|
|
|
Number of Regulators
|
1
|
|
|
Voltage – Input (Max)
|
45V
|
|
|
Voltage – Output (Min/Fixed)
|
2.5V
|
|
|
Voltage – Output (Max)
|
20V
|
|
|
Voltage Dropout (Max)
|
0.5V @ 250mA
|
|
|
Current – Output
|
400mA
|
|
|
Current – Quiescent (Iq)
|
200 µA
|
|
|
Current – Supply (Max)
|
35 mA
|
|
|
PSRR
|
70dB (100Hz)
|
|
|
Control Features
|
Enable
|
|
|
Protection Features
|
Over Temperature, Reverse Polarity, Short Circuit
|
|
|
Operating Temperature
|
-40°C ~ 150°C
|
|
|
Grade
|
Automotive
|
|
|
Qualification
|
AEC-Q100
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
TO-252-5, DPAK (4 Leads + Tab), TO-252AD
|
|
|
Supplier Device Package
|
DPAK-5
|
|
|
Base Product Number
|
NCV4276
|
