NCV4275ADT50RKG

The NCV4275A is an integrated low dropout regulator designed
for use in harsh automotive environments. It includes wide
operating temperature and input voltage ranges. The output is
regulated at 5.0 V or 3.3 V and is rated to 450 mA of output current.
It also provides a number of features, including overcurrent
protection, overtemperature protection and a programmable
microprocessor reset. The NCV4275A is available in the DPAK and
D2PAK surface mount packages. The output is stable over a wide
output capacitance and ESR range. The NCV4275A is pin for pin
compatible with NCV4275.

Categories: Linear Regulators, Power Management (PMIC)

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• 5.0 V and 3.3 V, ±2% Output Voltage Options
• 450 mA Output Current
• Very Low Current Consumption
• Active Reset Output
• Reset Low Down to VQ = 1.0 V
• 500 mV (max) Dropout Voltage
• Fault Protection
♦ +45 V Peak Transient Voltage
♦ −42 V Reverse Voltage
♦ Short Circuit Protection
♦ Thermal Overload Protection
• AEC−Q100 Grade 1 Qualified and PPAP Capable
• Pin Compatible with NCV4275
• These are Pb−Free Devices
