NCP161AMX300TBG

The NCP161 is a linear regulator capable of supplying 450 mA
output current. Designed to meet the requirements of RF and analog
circuits, the NCP161 device provides low noise, high PSRR, low
quiescent current, and very good load/line transients. The device is
designed to work with a 1 F input and a 1 F output ceramic capacitor.
It is available in two thickness ultra−small 0.35P, 0.64 mm x 0.64 mm
Chip Scale Package (CSP) and XDFN4 0.65P, 1 mm x 1 mm.

Categories: Power Management (PMIC), Regulators

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• Operating Input Voltage Range: 1.9 V to 5.5 V
• Available in Fixed Voltage Option: 1.8 V to 5.14 V
• ±2% Accuracy Over Load/Temperature
• Ultra Low Quiescent Current Typ. 18 A
• Standby Current: Typ. 0.1 A
• Very Low Dropout: 150 mV at 450 mA
• Ultra High PSRR: Typ. 98 dB at 20 mA, f = 1 kHz
• Ultra Low Noise: 10 VRMS
• Stable with a 1 F Small Case Size Ceramic Capacitors
• Available in −WLCSP4 0.64 mm x 0.64 mm x 0.4 mm
−WLCSP4 0.64 mm x 0.64 mm x 0.33 mm
−XDFN4 1 mm x 1 mm x 0.4 mm
−SOT23−5 2.9 mm x 2.8 mm x 1.2 mm
• These Devices are Pb−Free and are RoHS Compliant
Typical Applications
• Battery−powered Equipment
• Wireless LAN Devices
• Smartphones, Tablets
• Cameras, DVRs, STB and Camcorders
