    NC7WV16L6X

    The NC7WV16 is a dual buffer from Fairchild’s Ultra Low
    Power-A (ULP-A) series of TinyLogic. ULP-A is ideal for
    applications that require extreme high speed, high drive
    and low power. This product is designed for a wide low volt-
    age operating range (0.9V to 3.6V VCC ) and applications
    that require more drive and speed than the TinyLogic ULP
    series, but still offer best in class low power operation.
    The NC7WV16 is uniquely designed for optimized power
    and speed, and is fabricated with an advanced CMOS
    technology to achieve high-speed operation while main-
    taining low CMOS power dissipation.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      0.9V to 3.6V V CC supply operation
      3.6V overvoltage tolerant I/O’s at V CC from 0.9V to 3.6V
      Extremely High Speed tPD
      1.5 ns typ for 2.7V to 3.6V V CC
      1.8 ns typ for 2.3V to 2.7V V CC
      2.0 ns typ for 1.65V to 1.95V V CC
      3.2 ns typ for 1.4V to 1.6V V CC
      5.9 ns typ for 1.1V to 1.3V V CC
      12.0 ns typ for 0.9V V CC
      Power-Off high impedance inputs and outputs
      High Static Drive (I OH /IOL)
      ±24 mA @ 3.00V V CC
      ±18 mA @ 2.30V V CC
      ±6 mA @ 1.65V VCC
      ±4 mA @ 1.4V V CC
      ±2 mA @ 1.1V V CC
      ±0.1 mA @ 0.9V V CC
      Uses patented Quiet Series noise/EMI reduction
      circuitry
      Ultra small MicroPak leadfree package
      Ultra low dynamic power
