N25Q064A13E1240F
INQUIRY ONLINE
| Mfr | Infineon Technologies |
| Series | CoolMOS™ P7 |
| Packaging | Tube |
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 800 V |
| Current – Continuous Drain (Id) @ 25°C | 6A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 900mOhm @ 2.2A, 10V |
| Vgs(th) (Max) @ Id | 3.5V @ 110µA |
| Gate Charge (Qg) (Max) @ Vgs | 15 nC @ 10 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 350 pF @ 500 V |
| FET Feature | – |
| Power Dissipation (Max) | 26W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | PG-TO220-3-31 |
| Package / Case | TO-220-3 Full Pack |
| Base Product Number | IPA80R900 |
