    MX35LF1GE4AB-Z4I

    The MX35LF1GE4AB is a 1Gb SLC NAND Flash memory device with Serial interface.
    The memory array of this device adopted the same cell architecture as the parallel NAND, however
    implementing the industry standard serial interface.
    An internal 4-bit ECC logic is implemented in the chip, which is enabled by default. The internal ECC can be
    disabled or enabled again by command. When the internal 4-bit ECC logic is disabled, the host side needs
    to handle the 4-bit ECC by host micro controller.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • 1Gb SLC NAND Flash
      – Bus: x4
      – Page size: (2048+64) byte
      – Block size: (128K+4K) byte
      • Fast Read Access
      – Supports Random data read out by x1 x2 &
      x4 modes, (1-1-1,1-1-2, 1-1-4)Note 2
      – Latency of array to register: 25usNote1
      – Frequency: 104MHz
      • Page Program Operation
      – Page program time: 300us (typ)Note1
      • Block Erase Operation
      – Block erase time: 1ms (typ.)
      • Single Voltage Operation:
      – VCC: 2.7 to 3.6V
      • BP bits for block group protection
      • Low Power Dissipation
      – Max 30mA
      Active current (Read/Program/Erase)
      • Sleep Mode
      – 50uA (Max) standby current
      • High Reliability
      – Program / Erase Endurance: Typical 100K cycles
      (with internal 4-bit ECC per (512+16) Byte
      – Data Retention: 10 years
      • Wide Temperature Operating Range
      -40°C to +85°C
      • Package:
      8-WSON (8x6mm)
      All packaged devices are RoHS Compliant and
      Halogen-free.
      Note 1. Please refer to the tRD_ECC and
      tPROG_ECC specifications if internal ECC
      function is turned on.
      Note 2. Which indicates the number of I/O for
      command, address and data.
