MUN5214DW1T1G
INQUIRY ONLINE
|
Category
|
Discrete Semiconductor Products
Transistors
Bipolar (BJT)
Bipolar Transistor Arrays, Pre-Biased
|
|
|
Manufacturer
|
onsemi
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Transistor Type
|
2 NPN – Pre-Biased (Dual)
|
|
|
Current – Collector (Ic) (Max)
|
100mA
|
|
|
Voltage – Collector Emitter Breakdown (Max)
|
50V
|
|
|
Resistor – Base (R1)
|
10kOhms
|
|
|
Resistor – Emitter Base (R2)
|
47kOhms
|
|
|
DC Current Gain (hFE) (Min) @ Ic, Vce
|
80 @ 5mA, 10V
|
|
|
Vce Saturation (Max) @ Ib, Ic
|
250mV @ 300µA, 10mA
|
|
|
Current – Collector Cutoff (Max)
|
500nA
|
|
|
Frequency – Transition
|
–
|
|
|
Power – Max
|
250mW
|
|
|
Grade
|
–
|
|
|
Qualification
|
–
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
6-TSSOP, SC-88, SOT-363
|
|
|
Supplier Device Package
|
SC-88/SC70-6/SOT-363
|
|
|
Base Product Number
|
MUN5214
|
