MBI6655GSB-B

The NCP/NCV6323 is a synchronous buck converter which is
optimized to supply different sub systems of portable applications
powered by one cell Li−ion or three cell Alkaline/NiCd/NiMH
batteries. The devices are able to deliver up to 2 A on an external
adjustable voltage. Operation with 3 MHz switching frequency allows
employing small size inductor and capacitors. Input supply voltage
feedforward control is employed to deal with wide input voltage
range. Synchronous rectification offer improved system efficiency.
The NCP/NCV6323 is in a space saving, low profile 2.0 x 2.0 x
0.75 mm WDFN8 package or a WDFNW8 wettable flank package.

Category: Power Management (PMIC)

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• 2.5 V to 5.5 V Input Voltage Range
• External Adjustable Voltage
• Up to 2 A Output Current
• 3 MHz Switching Frequency
• Synchronous Rectification
• Enable Input
• Power Good Output Option
• Soft−Start
• Over Current Protection
• Active Discharge When Disabled
• Thermal Shutdown Protection
• WDFN8, 2 x 2 mm, 0.5 mm Pitch Package &
WDFNW8, 2 x 2 mm, 0.5 mm Pitch Package with Wettable Flanks
• Maximum 0.8 mm Height for Super Thin Applications
• NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
