MAX14930AASE+
INQUIRY ONLINE
|
Category
|
Isolators
Digital Isolators
|
|
|
Mfr
|
Analog Devices Inc./Maxim Integrated
|
|
|
Series
|
–
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Active
|
|
|
Technology
|
Capacitive Coupling
|
|
|
Type
|
General Purpose
|
|
|
Isolated Power
|
No
|
|
|
Number of Channels
|
4
|
|
|
Inputs – Side 1/Side 2
|
4/1
|
|
|
Channel Type
|
Unidirectional
|
|
|
Voltage – Isolation
|
2750Vrms
|
|
|
Common Mode Transient Immunity (Min)
|
25kV/µs (Typ)
|
|
|
Data Rate
|
1Mbps
|
|
|
Propagation Delay tpLH / tpHL (Max)
|
54.1ns, 55.3ns
|
|
|
Pulse Width Distortion (Max)
|
4.5ns
|
|
|
Rise / Fall Time (Typ)
|
2ns, 2ns
|
|
|
Voltage – Supply
|
1.71V ~ 5.5V
|
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
16-SOIC (0.154″, 3.90mm Width)
|
|
|
Supplier Device Package
|
16-SOIC
|
|
|
Base Product Number
|
MAX14930
|
