    M95256-WMN6TP

    The M95256 devices are electrically erasable programmable memories (EEPROMs) organized as 32768 x 8 bits,
    accessed through the SPI bus.
    The M95256-W can operate with a supply voltage from 2.5 V to 5.5 V, the M95256-R can operate with a supply
    voltage from 1.8 V to 5.5 V and the M95256-DF can operate with a supply voltage from 1.7 V to 5.5 V, over an
    ambient temperature range of -40 °C / +85 °C.
    The M95256-DF, -DR or -DW (hereinafter referred to as M95256-Dx) offer an additional page, named the
    Identification page (64 bytes). The Identification page can be used to store sensitive application parameters
    that can be (later) permanently locked in read-only mode.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Compatible with the serial peripheral interface (SPI) bus
      • Memory array
      – 256-Kbit (32 Kbytes) of EEPROM
      – Page size: 64 bytes
      – Additional write lockable page (Identification page)
      • Write time
      – Byte Write within 5 ms
      – Page Write within 5 ms
      • Write protect
      – quarter array
      – half array
      – whole memory array
      • High-speed clock: 20 MHz
      • Single supply voltage:
      – 2.5 V to 5.5 V for M95256-W
      – 1.8 V to 5.5 V for M95256-R
      – 1.7 V to 5.5 V for M95256-DF
      • Operating temperature range: from -40 °C up to +85 °C
      • Enhanced ESD protection
      • More than 4 million Write cycles
      • More than 200-year data retention
      • Packages
      – SO8N (ECOPACK2)
      – TSSOP8 (ECOPACK2)
      – UFDFPN8 (ECOPACK2)
      – WLCSP8 (ECOPACK2)
