    M24M02-DRMN6TP

    The M24M02 is a 2-Mbit I2C-compatible EEPROM (electrically erasable programmable memory) organized as
    256 K × 8 bits.
    The M24M02-DR and M24M02-R can operate with a supply voltage from 1.8 V to 5.5 V, over an ambient
    temperature range of –40 °C / +85 °C.
    The M24M02-DR offers an additional page, named the identification page (256 byte). The identification page can
    be used to store sensitive application parameters which can be (later) permanently locked in read-only mode.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Compatible with following I2C bus modes:
      – 1 MHz
      – 400 kHz
      – 100 kHz
      • Memory array:
      – 2 Mbit (256 Kbyte) of EEPROM
      – Page size: 256 byte
      – Additional write lockable page (M24M02-DR order codes)
      • Single supply voltage:
      – 1.8 V to 5.5 V over –40 °C / +85 °C
      • Write time:
      – Byte write within 10 ms
      – Page write within 10 ms
      • Random and sequential read modes
      • Write protect of the whole memory array
      • Enhanced ESD/latch-Up protection
      • More than 4 million write cycles
      • More than 200-years data retention
      • Packages:
      – SO8N ECOPACK2
      – WLCSP ECOPACK2
      – Unsawn wafer (each die is tested)
      – RoHS compliant and halogen-free (ECOPACK2)
