    M24256-BRMN6TP

    The M24256 is a 256-Kbit I2C-compatible EEPROM (electrically erasable programmable memory) organized as
    32 K × 8 bits.
    The M24256-BW can operate with a supply voltage from 2.5 V to 5.5 V, the M24256-BR AND M24256-DR can
    operate with a supply voltage from 1.8 V to 5.5 V, and the M24256-BF and M24256-DF can operate with a supply
    voltage from 1.7 V to 5.5 V. All these devices operate with a clock frequency of 1 MHz (or less), over an ambient
    temperature range of –40 °C / +85 °C. The M24256-D offers an additional page, named the identification page
    (64 byte). The identification page can be used to store sensitive application parameters which can be (later)
    permanently locked in read-only mode.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Compatible with following I2C bus modes:
      – 1 MHz
      – 400 kHz
      – 100 kHz
      • Memory array:
      – 256 Kbit (32 Kbyte) of EEPROM
      – Page size: 64 byte
      – Additional write lockable page (M24256-D order codes)
      • Single supply voltage and high speed:
      – 1 MHz clock from 1.7 V to 5.5 V
      • Write:
      – Byte write within 5 ms
      – Page write within 5 ms
      • Operating temperature range:
      – from -40 °C up to +85 °C
      • Random and sequential read modes
      • Write protect of the whole memory array
      • Enhanced ESD/latch-Up protection
      • More than 4 million write cycles
      • More than 200-years data retention
