    LT1965EMS8E#TRPBF

    The LT®1965 series are lownoise, lowdropout linearregulators. The devices supply 1.1A of output current with a
    310mVtypicaldropoutvoltage. Operatingquiescentcurrent
    is 500µA for the adjustable version, reducing to <1µA in
    shutdown. Quiescent current iswell controlled; it does not
    rise in dropout aswithmany otherregulators. The LT1965
    regulators have very low output noise which makes them
    ideal for sensitive RF and DSP supply applications.
    Output voltage ranges from 1.20V to 19.5V. The LT1965
    regulators are stable with output capacitors as low as
    10µF. Internalprotectioncircuitry includes reverse-battery
    protection, current limiting with foldback, thermal limiting and reverse-current protection. The LT1965 series
    are available in fixed output voltages of 1.5V, 1.8V, 2.5V,
    3.3V, and as an adjustable device with a 1.20V reference
    voltage. The package offerings include the 5-lead TO-220,
    5-lead DD-Pak as well as the thermally enhanced 8-lead
    MSOP and lowprofile (0.75mm) 8-lead 3mm× 3mmDFN.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      Output Current: 1.1A
      Dropout Voltage: 310mV
      Low Noise: 40µVRMS (10Hz to 100kHz)
      500µA Quiescent Current (Adjustable Version)
      Wide Input Voltage Range: 1.8V to 20V
      No Protection Diodes Needed
      Controlled Quiescent Current in Dropout
      Adjustable Output from 1.20V to 19.5V
      Fixed Output Voltages: 1.5V, 1.8V, 2.5V, 3.3V
      < 1µA Quiescent Current in Shutdown
      Stable with 10µF Output Capacitor
      Stable with Ceramic or Tantalum Capacitors
      Reverse-Battery Protection
      No Reverse Current
      Current Limit with Foldback Protection
      Thermal Limiting
      5-Lead TO-220, DD-Pak, Thermally Enhanced 8-Lead
      MSOP and 8-Lead 3mm × 3mm DFN Packages
