    LSP5523-R8A

    The DIODES™ LSP5523 is a monolithic synchronous buck regulator. The device integrates 90mΩ MOSFETS
    that provide 3A continuous load current over a wide operating input voltage of 4.5V to 27V. Current mode
    control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents
    inrush current at turn on.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

       3A Output Current
       Wide 4.5V to 27V Operating Input Range
       Fixed 340KHZ Frequency
       Integrated Power MOSFET Switches
       Output Adjustable from 0.925V to 0.8Vin
       Up to 93% Efficiency
       Programmable Soft-Start
       Stable with Low ESR Ceramic Output Capacitors
       Cycle by Cycle Over Current Protection
       Short Circuit Protection
       Input Under Voltage Lockout
       Package: ESOP-8L
       Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
       Halogen and Antimony Free. “Green” Device (Note 3)
