LMZM23601SILR
INQUIRY ONLINE
|
Category
|
Power Supplies – Board Mount
DC DC Converters
|
|
|
Mfr
|
Texas Instruments
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Type
|
Non-Isolated PoL Module
|
|
|
Number of Outputs
|
1
|
|
|
Voltage – Input (Min)
|
4V
|
|
|
Voltage – Input (Max)
|
36V
|
|
|
Voltage – Output 1
|
1.2 ~ 15V
|
|
|
Voltage – Output 2
|
–
|
|
|
Voltage – Output 3
|
–
|
|
|
Voltage – Output 4
|
–
|
|
|
Current – Output (Max)
|
1A
|
|
|
Applications
|
ITE (Commercial)
|
|
|
Features
|
OCP, SCP, UVLO
|
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
|
Efficiency
|
–
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
10-LDFN Exposed Pad, Module
|
|
|
Size / Dimension
|
0.15″ L x 0.12″ W x 0.06″ H (3.8mm x 3.0mm x 1.6mm)
|
|
|
Supplier Device Package
|
10-uSIP (3.8×3)
|
|
|
Base Product Number
|
LMZM23601
|
