LMR36006AQRNXRQ1

• AEC-Q100-qualified for automotive applications:
– Temperature grade 1: –40°C to +125°C, TA
• Functional Safety-Capable
– Documentation available to aid functional safety
system design
• Designed for automotive applications
– Junction temperature range –40°C to +150°C
– Protection features: thermal shutdown, input
undervoltage lockout, cycle-by-cycle current
limit, hiccup short-circuit protection
– 0.2-V dropout with 0.6-A load (typical)
– ±1.5% reference voltage tolerance
– 3.3-V fixed-output voltage option available
• Suited for scalable power supplies
– Pin compatible with:
• LMR36015-Q1 (60 V, 1.5 A)
• LMR33620/30-Q1 (36 V, 2 A, or 3 A)
– 400-kHz, 2.1-MHz frequency options
• Integration reduces solution size and cost
– Small, 2-mm × 3-mm VQFN package with
wettable flanks
– Few external components
• Low power dissipation across load spectrum
– 94% efficiency at 400 kHz (12 VIN, 5 VOUT, 0.6
A)
– Increased light load efficiency in PFM
– Low operating quiescent current of 26 µA
• Optimized for ultra low EMI requirements
– Meets CISPR25 class 5 standard
– HotRod™ package minimizes switch node
ringing
– Parallel input path minimizes parasitic
inductance
– Spread spectrum reduces peak emissions
• Create a custom design using the LMR36006-Q1
with the WEBENCH® Power Designer
