LM358DT

These circuits consist of two independent, highgain, internally frequency-compensated op amps,
specifically designed to operate from a single
power supply over a wide range of voltages. The
low-power supply drain is independent of the
magnitude of the power supply voltage.
Application areas include transducer amplifiers,
DC gain blocks and all the conventional op amp
circuits, which can now be more easily
implemented in single power supply systems. For
example, these circuits can be directly supplied
with the standard 5 V, which is used in logic
systems and will easily provide the required
interface electronics with no additional power
supply.
In linear mode, the input common-mode voltage
range includes ground and the output voltage can
also swing to ground, even though operated from
only a single power supply voltage.

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

     Frequency compensation implemented
    internally
     Large DC voltage gain: 100 dB
     Wide bandwidth (unity gain): 1.1 MHz
    (temperature compensated)
     Very low supply current per channel
    essentially independent of supply voltage
     Low input bias current: 20 nA (temperature
    compensated)
     Low input offset voltage: 2 mV
     Low input offset current: 2 nA
     Input common-mode voltage range includes
    negative rails
     Differential input voltage range equal to the
    power supply voltage
     Large output voltage swing
    0 V to (VCC+
    – 1.5 V)
