LB11961-W-AH

The LB11961 is a single-phase bipolar drive motor driver that easily
implements direct PWM motor drive systems with excellent efficiency. The
LB11961 is optimal for fan motor drive in personal computer power supply
systems and CPU cooling fan systems


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • Single-phase full-wave drive (16V, 1.0A transistors are built in)
    • Built-in variable speed function controlled by a thermistor input
    The LB11961 can implement quiet, low-vibration variable speed control
    using externally clocked high side transistor direct PWM drive.
    • Built-in regenerative diode (Di); only requires a minimal number of external
    components.
    • Built-in HB
    • Minimum speed setting pin (allows full-speed mode operation at startup)
    • Operates in full-speed mode when the thermistor is removed.
    • Built-in lock protection and automatic recovery circuits
    • FG (speed detection) and RD (lock detection) outputs
    • Built-in thermal shutdown circuit
