ISL80020AFRZ

The ISL80020, ISL80020A, ISL80015 and ISL80015A are highly
efficient, monolithic, synchronous step-down DC/DC converters
that can deliver up to 2A of continuous output current from a 2.7V
to 5.5V input supply. They use peak current mode control
architecture to allow very low duty cycle operation. They operate
at either 1MHz or 2MHz switching frequency, thereby providing
superior transient response and allowing for the use of small
inductors. They have excellent stability.
The ISL80020, ISL80020A, ISL80015 and ISL80015A integrate
very low rDS(ON) MOSFETs in order to maximize efficiency. In
addition, since the high-side MOSFET is a PMOS, the need for a
Boot capacitor is eliminated, thereby reducing external
component count. They can operate at 100% duty cycle
(at 1MHz).
The device is configured in PWM (pulse width modulation) for
fast transient response, which helps reduce the output noise
and RF interference.
These devices are offered in a space saving 8 pin 2mmx2mm
TDFN lead free package with exposed pad for improved thermal
performance. The complete converter occupies less than
