    IS63WV1288DBLL-10HLI-TR

    The ISSI IS63/64WV1288Dxxx is a very high-speed,
    low power, 131,072-word by 8-bit CMOS static RAM.
    The IS63/64WV1288DBLL is fabricated using ISSI’s
    high-performance CMOS technology. This highly reliable
    process coupled with innovative circuit design
    techniques, yields higher performance and low power
    consumption devices.
    When CE is HIGH (deselected), the device assumes a
    standby mode at which the power dissipation can be reduced down to 25 µW (typical) with CMOS input levels.
    The IS63/64WV1288DBLL operates from a single Vdd
    power supply. The IS63/64WV1288Dxxx is available in
    32-pin TSOP (Type II), 32-pin sTSOP (Type I), 48-Ball
    miniBGA (6mm x 8mm) and 32-pin SOJ (300-mil) packages.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      HIGH SPEED: (IS63/64WV1288DALL/DBLL)
      • High-speed access time: 8, 10, 12, 20 ns
      • Low Active Power: 135 mW (typical)
      • Low Standby Power: 12 µW (typical)
      CMOS standby
      LOW POWER: (IS63/64WV1288DALS/DBLS)
      • High-speed access time: 25, 35 ns
      • Low Active Power: 55 mW (typical)
      • Low Standby Power: 12 µW (typical)
      CMOS standby
      • Single power supply
      — Vdd 1.65V to 2.2V (IS63WV1288DAxx)
      — Vdd 2.4V to 3.6V (IS63/64WV1288DBxx)
      • Multiple center power and ground pins for
      greater noise immunity
      • Easy memory expansion with CE and OE options
      • CE power-down
      • Fully static operation: no clock or refresh
      required
      • TTL compatible inputs and outputs
      • Lead-free available
