IRFR3708TRPBF
INQUIRY ONLINE
|
Category
|
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single
|
|
|
Mfr
|
Infineon Technologies
|
|
|
Series
|
HEXFET®
|
|
|
Packaging
|
Tape & Reel (TR)
|
|
|
Part Status
|
Obsolete
|
|
|
FET Type
|
N-Channel
|
|
|
Technology
|
MOSFET (Metal Oxide)
|
|
|
Drain to Source Voltage (Vdss)
|
30 V
|
|
|
Current – Continuous Drain (Id) @ 25°C
|
61A (Tc)
|
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
2.8V, 10V
|
|
|
Rds On (Max) @ Id, Vgs
|
12.5mOhm @ 15A, 10V
|
|
|
Vgs(th) (Max) @ Id
|
2V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs
|
24 nC @ 4.5 V
|
|
|
Vgs (Max)
|
±12V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
2417 pF @ 15 V
|
|
|
FET Feature
|
–
|
|
|
Power Dissipation (Max)
|
87W (Tc)
|
|
|
Operating Temperature
|
-55°C ~ 175°C (TJ)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Supplier Device Package
|
TO-252AA (DPAK)
|
|
|
Package / Case
|
TO-252-3, DPAK (2 Leads + Tab), SC-63
|
