IR2104STRPBF

The IR2104(S) are high voltage, high speed power
MOSFET and IGBT drivers with dependent high and low
side referenced output channels. Proprietary HVIC and
latch immune CMOS technologies enable ruggedized
monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic.
The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. The
floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which
operates from 10 to 600 volts.


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • Floating channel designed for bootstrap operation
    Fully operational to +600V
    Tolerant to negative transient voltage
    dV/dt immune
    • Gate drive supply range from 10 to 20V
    • Undervoltage lockout
    • 3.3V, 5V and 15V input logic compatible
    • Cross-conduction prevention logic
    • Internally set deadtime
    • High side output in phase with input
    • Shut down input turns off both channels
    • Matched propagation delay for both channels
    • Also available LEAD-FREE
